RUCKUS R770 Indoor Access Point

Very-High-Performance Tri-Radio Wi-Fi 7 2x2:2 | 4x4:4 | 2x2:2 Indoor Access Point with 12.22 Gbps max rate and Embedded IoT

RUCKUS R770 Leads the Wi-Fi 7 Revolution

Ultra-fast, low latency wireless connections with improved capacity and efficiency

Wi-Fi 7’s extreme speed, low latency and increased capacity delivers exceptional user experiences and empowers an entirely new class of advanced connected devices and demanding applications. Need a way for wireless devices to support 8K video streams, extended reality (XR) video conferencing, massive social gaming, and more? Wi-Fi 7 is the answer and RUCKUS® brings it to life with the R770 as the first enterprise-class AP supporting Wi-Fi 7 to hit the market.

RUCKUS Wi-Fi 7 implementation is further enhanced by RUCKUS BeamFlex+ patented smart, directional antenna technology and RUCKUS AI to optimize network performance.

Innovation of the year award 2024 RUCKUS Networks Wi-Fi award
R770 wins Innovation of the Year!

We're proud to announce that our AI-driven R770 access point (AP) has been designated as the “Innovation of the Year” by the Wi-Fi Awards.

阅读更多

Icons_Accelerate

Superior Throughput and Capacity

  • RUCKUS BeamFlex+ on all three bands dramatically improves throughput and range.
  • 4K QAM and 320 MHz wide channels take full advantage of the 6 GHz spectrum and deliver unprecedented throughput
  • 10 Gbps Ethernet port eliminates backhaul bottleneck
  • AI Driven Radio Resources Management simplifies support and enhances network performance
  • Automated Frequency Coordination (AFC) boosts signal strength and range by enabling the use of Standard Power (SP) mode at 6 GHz

Icons-adaptability

Adaptive Resilience

  • Multi Link Operation (MLO) improves reliability by transmitting data across multiple links to prevent interruptions.
  • Better Wi-Fi resiliency through AI driven automated incident classification and recommended remediation steps

Icons_GlobalLeader

Reduced Latency

  • RUCKUS Wi-Fi 7 enhancements including smart QoS mirroring deliver the deterministic latency applications need
  • Wi-Fi 7 new set of QoS features to improve user experience in various scenarios.

Icons-simplicity

Advanced Security Simplified

  • RUCKUS exclusive DPSK3 adds the power of DPSK to WPA3 combining advanced security with the flexibility and ease of use of dynamic passphrase to secure network access.
  • Secure boot and TPM 2.0 offers hardware-level protection against malware and sophisticated cyberattacks

IoT-networking

Built-in Modern IoT Stack

  • Built-in IoT radio for BLE & Zigbee support and USB port for additional expandability
  • Broad Pre-integrated IoT solutions/ecosystems
  • Matter and Thread ready*

Specifications for RUCKUS R770 Indoor Access Point

R770 | RUCKUS R770 Indoor Access Point [RUCKUS R770 Access Point - 0L5A7207]
地区供货情况 亚洲 | 澳大利亚/新西兰 | 欧洲和中东 | 拉丁美洲 | 北美洲
产品类型 室内接入点
产品品牌 RUCKUS®
Antenna Patterns, per band 4000+
Antenna Gain Up to 4 dBi
BeamFlex
ChannelFly
并发用户 1024
Controller Support RUCKUS One™ | RUCKUS SmartZone | RUCKUS Unleashed™ | Standalone
以太网端口 1 x 1 / 2.5 / 5 /10 GbE | 1 x 1 GbE
物联网支持 机载物联网
无线电频段数量 三频
PD-MRC
PHY Rate at 2.4 GHz, maximum 689 Mb/s
PHY Rate at 5 GHz, maximum 5765 Mb/s
PHY Rate at 6 GHz, maximum 5765 Mb/s
Combined Max PHY Rate 12220 Mb/s
无线电链和流 2x2:2 (2.4 GHz) 4x4:4 (5 GHz) 2x2:2 (6 GHz)
Rx Sensitivity at 2.4 GHz -97 dBm
Rx Sensitivity at 5 GHz -100 dBm
Rx Sensitivity at 6 GHz -96 dBm
SmartMesh
USB USB 2.0
场地类型 教育 | 酒店业 | MDU | 生产 | 营业处/零售 | 公共场所
场地子类型 会议厅 | 演讲厅 | 中转站 | 场地公共场所
支持的Wi-Fi频段 2.4 GHz | 5 GHz | 6 GHz
Wi-Fi世代 Wi-Fi 7
Wi-Fi接口标准 IEEE 802.11a/b/g/n/ac/ax/be
工作温度 0 °C to +50 °C (+32 °F to +122 °F)
